Bitmain ANTRACK V2 24 kW (Hydro Mining System) for ASIC Miners
The Bitmain ANTRACK V2 is a professional hydro mining system with a separate external cooling unit, designed for compatible liquid-cooled ASIC miners. It includes a mining cabinet, water pump and external cooler, with a specified maximum cooling capacity of 24 kW. The system accommodates up to four compatible Antminer Hydro units or two compatible U3 Hydro units. Contact us before ordering to confirm hardware compatibility and installation requirements.
Request sent. We will contact you shortly.
| Bitmain ANTRACK V2 – Technical Specifications | : |
|---|---|
| Manufacturer | Bitmain |
| Model | ANTRACK V2 |
| Product type | Hydro mining system with external cooling unit |
| Maximum cooling capacity | 24 kW |
| Miner capacity | Up to 4 compatible Antminer Hydro units or 2 compatible U3 Hydro units |
| Power supply | 380–415 V AC, three-phase |
| Frequency | 50–60 Hz |
| Maximum input current | 63 A |
| Mining Cabinet | : |
| External Cooling Unit | : |
| Dimensions | 1,197 × 650 × 1,177 mm |
| Weight | 112 kg |
| Fan power | 750 W |
| Water Pump | : |
| Power consumption | 450 W |
| Approximate noise level | 60 dB |
| Maximum head | 19 m |
| Cooling System Specifications | : |
| Coolant | Water with approximately 10% antifreeze, subject to manufacturer requirements |
| Coolant pH | 7.8–8.5 |
| Operating Conditions | : |
| Specified temperature range | −20 to 40°C |
| Relative humidity | 10–90%, non-condensing |
| General Hydro Miner Specifications | : |
| Operating temperature | 0–40°C |
| Coolant inlet temperature | 20–40°C |
| Coolant flow rate | 8 L/min ±10% per miner |
| Maximum coolant pressure | 3.5 bar |
| Storage temperature | −20 to 70°C |
| Operating humidity | 10–90% RH, non-condensing |
| Miner power supply | Three-phase, depending on model |
| Cooling equipment power supply | Single-phase, depending on configuration |
The Bitmain ANTRACK V2 Hydro Mining System is a professional liquid-cooling solution designed for hydro-cooled ASIC miners. It combines a mining cabinet, a water pump and a separate external cooling unit to help maintain suitable operating temperatures for mining hardware.
Unlike the integrated ANTRACK V1 cabinet, the ANTRACK V2 uses a separate external cooler. The miners are housed in the main cabinet, while heated coolant circulates through a closed loop to the external cooling unit, where heat is dissipated before the coolant returns to the miners. The external unit can be positioned outdoors when the installation and environmental conditions allow.
The system is designed for up to four compatible Antminer Hydro units or two compatible U3 Hydro units, subject to model-specific requirements. Potential compatibility with Whatsminer Hydro models and other liquid-cooled ASIC miners should be confirmed before purchase.
Key Features and Benefits
- Separate external cooling unit: Transfers heat away from the main mining cabinet.
- Up to 24 kW cooling capacity: The specified maximum cooling capacity is not the system’s electrical power consumption.
- Flexible miner capacity: Designed for up to four compatible Antminer Hydro miners or two compatible U3 Hydro units.
- Integrated water pump: Circulates coolant through the closed-loop cooling system.
- Heat management: Helps remove heat generated by mining hardware and can reduce the heat load inside the mining area.
- Potential heat recovery: Waste heat may be reused for building heating or water heating with a suitable installation.
- Professional mining applications: Suitable for mining farms and installations designed for liquid-cooled ASIC hardware.
Installation and Operating Requirements
The ANTRACK V2 requires appropriate electrical infrastructure and a correctly designed cooling loop.
- Use a suitable coolant, such as the specified water and antifreeze mixture or another manufacturer-approved coolant.
- Avoid prolonged use of untreated tap water.
- Maintain the recommended coolant flow rate, pressure and temperature.
- Regularly inspect the coolant, filtration and cleanliness of the cooling circuit.
- Ensure the electrical installation meets the system’s three-phase power requirements.
- Confirm the required voltage, current capacity and protective equipment before installation.
- If the external cooling unit is installed outdoors, ensure that its placement and environmental protection meet the manufacturer’s requirements.
Important: Compatibility, coolant requirements, electrical installation and cooling performance must be verified for the exact hardware configuration. The stated 24 kW is the maximum cooling capacity, not the system’s electricity consumption.
For long-term operation, we also recommend considering a professional ASIC miner hosting solution with suitable cooling, filtration and technical support.
Need help choosing the right setup? Contact us before ordering. We can help you assess miner compatibility and plan a suitable hydro-mining installation.
